CAMERA >FPV Cameras

CADDX Turbo S1
(2.3mm Lens)
1/3 CCD 600TVL IR Blocked FPV Camera
Products
Description
Price in SGD


Caddx Turbo S1 1/3 CCD 600TVL 4:3
2.3mm M10 Lens FPV Camera (Yellow)
PAL DC: 5V-40V Wide Voltage



Specifications:
Model: Turbo S1
Image Sensor: 1/3" CCD Sensor
Horizontal Resolution: 600 TVL
TV System: PAL
Synchronization: Internal
Ratio: 4:3
Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
S/N Ratio: >60dB (AGC OFF)
Video Output: CVBS
Lens: 2.3mm
Lens Screw Diameter: M10
Min. Illumination: 0.01Lux@F1.2
Auto Gain Control: YES
BLC: YES
FLY OSD: Voltage/time/horizontal line/title
Camera OSD: YES
WDR: D-WDR
DNR: 2 DNR
Day/Night: Auto/Color/B&W
Connector: Molex PicoBlade 1.25mm 4P
Wide Power Input: DC 5-40V
Work Temperature: -20°
C~+60°C
Work Humidity: 20%~80%
Dimensions: 22mm*22mm*27mm
Weight: 12g (N.W.)/ (G.W.)

Package Contents:
1 x Caddx Turbo S1 600TVL Camera
1 x 5D-OSD Menu Board
1 x ABS+PV Bracket
1 x Aluminum Bracket
1 x 4pin FPV silicone cable (extend into a 2pin joint for OSD board and a 3pin joint for FPV)
1 x Screws set 1 x Manual

SGD$43.00
(Turbo S1)


























CADDX Turbo Micro S1
(2.1mm Lens)
1/3 CCD 600TVL IR Blocked FPV Camera
Products
Description
Price in SGD


Caddx Turbo MICRO S1 1/3 CCD 600TVL 4:3
2.1mm M10 Lens FPV Camera (Yellow)
PAL DC: 5V-40V Wide Voltage



Specifications:
Brand: Caddx
Model: Turbo Micro S1
Image Sensor: 1/3" CCD Sensor
Horizontal Resolution : 600TVL
Lens: 2.1mm
Screen Format: 4:3
Signal System: PAL
Synchronization: Internal
Video Output: CVBS
S/N Ratio: >60dB (AGC OFF)
Electronic Shutter: 1/50 - 100,000
Auto Gain Control: Yes
BLC: Yes
Fly OSD: Voltage/Time/Horizontal Line/Title
Camera OSD: Yes
Min. Illumination: 0.01Lux@1.2F
WDR: D-WDR
DNR: 2 DNR
Day/Night: Auto / Color / B&W
Wide Power Input: DC 5-40V
Work Humidity: 20% - 80%

Net Weight: 5g
Dimensions: 19 X 19 X 19mm

Package Contents:
1 x Camera
1 x Aluminum Bracket
1 x FPV Silicone Cable (4-Pin Port One Side, 3-Pin Port The Other Side)
1 x Internal Hexagonal Wrench
1 x Warranty Card

SGD$39.50
(Turbo MICRO S1)
